Flying Test Systems Ltd (FTSL), a specialist in PCBA test solutions, benchmarked three boundary scan systems when it became unhappy with the one it had used for several years. The comparison revealed one clear winner, and their engineers switched to using XJTAG. FTSL now integrates XJTAG boundary scan into many of its test solutions.

FTSL decided to benchmark different boundary scan test systems after it became unhappy with how slowly support requests were being resolved for its existing boundary scan solution. One key item in their comparison was how long it took to create a working test project, and the results were clear: with the XJTAG system, the project was running after just half a day whereas solutions from other providers took up to three days. “From a business perspective, that made XJTAG an obvious choice,” said Nigel Priest, FTSL’s Managing Director: development time is very important to his busy company and to its clients.

The other advantages of XJTAG also quickly became apparent. For example, they discovered how effectively it maximised test coverage across the board. Priest said, “What it delivered straight out of the box was quite incredible in terms of the depth of coverage.”

FTSL’s engineers also found how easy the XJTAG system is to use, especially with its user-friendly graphical interface. Cheryl Rogers, FTSL’s Commercial Director, commented, “Our engineers who do the boundary scan work love the XJTAG system. It’s so much easier.”

Depending on the client’s needs, the tests that FTSL develop may be executed from XJRunner’s GUI, or integrated into a system built using National Instruments™ LabVIEW™.

“Another advantage is the ability to program at full speed,” Priest said. FTSL uses both XJFlash (which utilises the board’s FPGA as a vehicle for ultra-fast memory programming) and XJDirect (which is used when memory is connected to a microprocessor).

Priest concluded, “The XJTAG tools and the interface are clearly best in class.”
