PC CAN Hardware

PC CAN Couplers & Converters

PCAN-Optoadapter

The PCAN-Optoadapter is a universal plug-on adapter to allow galvanic isolation of High-speed CAN bus systems.

Its integrated logic means that decoupling can be installed at any point in the CAN network.

The PCAN-Optoadapter can be used in CAN FD busses with data bit rates up to 2 Mbit/s and nominal bit rates up to 1 Mbit/s.

PCAN-Repeater DR

The PCAN-Repeater DR establishes a connection between two High-speed CAN busses with galvanic isolation of up to 5 kV. Both CAN channels are decoupled from each other and from the power supply. All message traffic including error frames is forwarded 1:1 between both channels, if necessary, in one direction only. The PCAN-Repeater DR behaves passively and is transparent from the perspective of the CAN bus. LEDs display the current bus status. With its DIN rail casing and extended temperature range support, this module is suitable for use in an industrial environment.

PCAN-LWL

For use in explosion-proof areas or for EMC measurements, the PCAN-LWL can be used to replace a stretch of CAN network with a fiber-optic line at any point. There are the options of conversion to High-speed CAN or Low-speed CAN. The modules are supplied with power externally.

The PCAN-LWL can be used in CAN FD busses with data bit rates up to 5 Mbit/s and nominal bit rates up to 500 kbit/s.

PLIN-LWL

For use in explosion-proof areas or for EMC measurements, the PLIN-LWL can be used to replace a stretch of LIN network with a fiber-optic line at any point. The modules are supplied with power externally.

PCAN-AU5790

The PCAN-AU5790 bus converter establishes a connection between a High-speed CAN bus (ISO 11898-2) and a Single-wire CAN bus (SAE J2411). One of the most important potential applications of the bus converter is a simple connection between a PEAK CAN interface (e.g. PCAN-USB) and a Single-wire CAN bus.

PCAN-B10011S

The PCAN-B10011S bus converter establishes a connection between a High-speed CAN bus (ISO 11898-2) and a Truck Trailer CAN bus (ISO 11992-1). One of the most important potential applications of the bus converter is a simple connection between a PEAK CAN interface (e.g. PCAN-USB) and a Truck Trailer CAN bus.

PCAN-TJA1054

The PCAN-TJA1054 bus converter provides a connection between a high-speed CAN bus (ISO 11898-2) and a low-speed CAN bus (ISO 11898-3).�The possible applications of the bus converter include the simple connection of a CAN interface of the PCAN series (eg PCAN-USB) to a low-speed CAN bus.
